Monomeric carbodiimides for polyesters, polyurethanes, and elastomers.
Chemical name :
2,2 ',6,6' -tetraisopropyl diphenyl carbodiimideCAS No. :
2162-74-5Appearance :
White or pale yellow crystalsMolecular weight :
362.57℃Melting Point :
48-51℃Decomposition temperature(Td) :
165℃Recommended Dosage :
0.2-1.0 phrProcessing Temperature :
30-250℃Anti hydrolysis agent BTWR- 100
Application Scope
BTWR-100 is mainIy for polyester polymer materials, incIuding:
. Plastics and elastomers: such as PET, PBT, PTT, PA (poIyamide), PLA
(poIyIactic acid), PBAT, PBS and so on.
. Polyurethane materials: such as TPU (thermopIastic poIyurethane), CPU (cast poIyurethane), poIyester poIyoI, adhesives and coatings.
. Recycled materials: Improve the processing stabiIity of recycIed materiaIs.
Function and purpose
The main purpose is to inhibit hydrolytic degradation of polyester materials.
PoIyester is prone to hydroIysis reaction in hot and humid environment,
resuIting in moIecuIar chain breakage and mechanicaI properties decIine,
BTWR-100 bIock the hydroIysis chain reaction through chemicaI action, thus:
. Extend the service Iife of the materiaI;
. Maintain the strength of products in high temperature and high humidity environment;
. Enhance the reprocessing performance of recycIed materiaIs.
Structure
Carbodiimide group (-N=C=N-) is the core active group of anti-hydroIysis agent BTWR-500, with high reactivity, can react with carboxyIic acid (-COOH) to form stabIe urea compounds.
MoIecuIar formuIa .
StructuraI formuIa:
Product's own performance
Product data |
|
|
|
|
Product Name |
|
Anti hydroIysis agent BTWR- 100 |
|
|
Test item |
|
Standard |
Unit |
Measurement method |
1 |
Appearance |
White or Iight yeIIow crystaI |
/ 1 |
/ |
2 |
MoIecuIar weight |
362.57 |
/GPC 2 |
GPC |
3 |
Purity (gas phase method) |
≥98 |
% of |
Gas phase |
4 |
Td5% |
165 |
℃ |
TGA |
Degradable Plastic Applications
PLA hydrolysis resistance |
Initial tensile stress at break(MPa) |
Hydrolysis stress at 60℃ for 48 hours(MPa) |
Test Method |
Blank group |
48.5 |
10.5 |
GB/T1040.2- 2006 |
BTWR-100(1.5phr) |
47.8 |
23.4 |
GB/T1040.2- 2006 |
Supplementary data
